Product Overview
The GTS-3SMJZ is a high-performance rugged laptop designed for mission-critical operations in harsh and mobile environments, integrating computing, communication, and positioning into a single platform. Built with a CNC-machined aluminum-magnesium alloy chassis, it delivers durability and stability while housing an Intel multi-core processor for reliable field performance. Compared to previous models, it features a built-in 6400mAh battery, integrated GPS, and 4G LTE connectivity, enabling true standalone deployment without external dependencies.
With its modular architecture, PCIe expansion capability, and rich I/O interfaces, the GTS-3SMJZ can be easily adapted for diverse applications such as tactical command, mobile communication, and industrial field operations, providing users with a flexible and dependable solution in demanding scenarios.
Key Features
|
No. |
Feature Category |
Description |
|
1 |
All-in-One Mobility |
Built-in 6400mAh battery, integrated GPS and 4G LTE for standalone field operation |
|
2 |
High Performance Computing |
Intel i5-8500T processor (6 cores, up to 4.4 GHz) for demanding workloads |
|
3 |
Ruggedized Structure |
Aluminum-magnesium alloy housing with CNC integrated molding |
|
4 |
Modular Expansion Capability |
Full-size PCIe x16 slot for mission-specific hardware integration |
|
5 |
Full HD Display |
15.6” 1920×1080 display with 300 cd/m² brightness for outdoor readability |
|
6 |
Rich I/O Interfaces |
Multiple USB, LAN, HDMI, COM ports for industrial connectivity |
|
7 |
Integrated Communication |
Built-in LTE and GPS modules with external antenna support |
|
8 |
Field-Oriented Design |
Card-reader expansion space and customizable configurations |
|
9 |
Wide Environment Adaptability |
Operates from -10°C to 60°C in non-condensing environments |
Technical Specifications
|
No. |
Category |
Specification |
|
1 |
Display |
15.6” TFT LED, 1920×1080, 300 cd/m² |
|
2 |
Processor |
Intel i5-12500T, 6 cores / 12 threads, 2.0–4.4 GHz Higher-performance CPU can be customized. |
|
3 |
Memory |
16GB DDR5 (8GB×2), up to 64GB |
|
4 |
Storage |
1TB SSD |
|
5 |
Graphics |
Intel integrated graphics |
|
6 |
Operating System |
Windows 10 / 11 |
|
7 |
Camera |
Built-in 5MP camera |
|
8 |
Audio |
Dual speakers + microphone, Mic & Line-out |
|
9 |
Wireless |
Built-in 4G LTE (external antenna) |
|
10 |
Positioning |
Built-in GPS (external antenna) |
|
11 |
I/O Ports |
USB3.0×4, USB2.0×2, LAN×2, HDMI×1, COM×2, DC-IN |
|
12 |
Expansion |
1× PCIe x16 full-size slot |
|
13 |
Battery |
6400mAh, ≥2 hours operation |
|
14 |
Power Supply |
180W adapter (AC 100–240V, DC 19V) |
|
15 |
Material |
Aluminum-magnesium alloy |
|
16 |
Dimensions |
380 × 280 × 65.5 mm |
|
17 |
Weight |
5.5 kg |
|
18 |
Operating Temp. |
-10°C to 60°C |
|
19 |
Storage Temp. |
-20°C to 65°C |
|
20 |
Humidity |
5%–90% (non-condensing) |
