Web Management 10/100/1000M Ethernet Media Converter

Compliant with Ethernet standard IEEE802.3 and IEEE802.3u, Global Tech G series Media Converter supports Bandwidth Control and Fault Shifting functions. G series Media Converter can inter-convert the transmission of Ethernet signals between over the twisted pair medium, as 10BASE-TX ,100BASE-TX and 1000 BASE-TX, and over the optical fiber medium, as 10/100/1000 Base-TX

G series Media Converter can realize the Ethernet signal long distance transmission with the optical fiber inherent characteristics and advantages.





lHigh Frequency Communication Power Supply with the built-in lightning protection circuit, greatly reduce the damages caused by lightning; and a high degree of electromagnetic shielding character and outstanding electromagnetic compatibility.
lBandwidth Control support N* 32K configurable; Optional Linkloss function, Fault Shifting; Optional enable or disable the Pause frame pass through configuration.
lSupport store-and-forward mode and cut-through mode. The store-and-forward mode supports long frame up to 2046 Bytes, with 9K Bytes in cut-through mode. With store-and-forward buffer, effectively improve the transmission efficiency of terminating equipment to realize flow control, broadcast isolation, and error detection. Through the flexible network management, 10M/100M/1000M, full/half duplex, adaptive /non-adaptive states are configurable.
lSupport IEEE802.1Q standard to guarantee most of network products VLAN features, such as cross-switch VLAN and TRUNK function.
lSophisticated working status indications, present the connection status of the local end Ethernet, such as connection/idle, full/ half duplex, and working rate; Network management can monitor the remote end NE working status, configure and reset the NE.





lOptical Interface
nWavelength: 1310nm, 1550nm
nConnector Type: FC, SC
nTransmission Distance: 2/20/40/60/80/120 km

lEthernet Interface
n10M/100M/1000M auto negotiation
nTransmission Distance: 100m
nCable Type: Cat.5 UTP
nMDI/ MDIX auto negotiation
nCompatibility: Cooperate with all standard network equipments and no packet loss in all working mode.
nRelated Standards
IEEE 802.3: Ethernet Standard
IEEE 802.3u: Fast Ethernet
IEEE 802.3x: Flow Control
IEEE 802.1d: Ethernet STP
IEEE 802.1Q: Ethernet Virtual LAN
IEEE 802.3ad: Link Aggregation
IEEE 802.1x: Port-based Network Access Control

lOperation Environment
nWorking Temperature: -10℃~ 70℃
nStorage Temperature: -40℃~ 85℃
nRelative Humidity: 5%~ 95%, non-condensing
No corrosive and solvent gas, no dust and heavy EMI
nPower Supply: AC: 180V~240V
nTypical Consumption: <5W
nPhysical Dimension:
Desktop: 175mm(W)*37mm(H)*137mm(D)
Card:2U Faceplate: 92mm(W)*25mm(D)
4U Faceplate: 174mm(W)*20mm(D)
